GG - flange straight High-grade, specially formulated polyamide 6
Flange seal FG04 made from EPDM
Flange seal FG04/01 made from NBR，on request
Very high impact strength
Vibration-proof connection to PMAFLEX conduits
High conduit pull-out strength
Ingress protection: IP50 (IP65 with conduit seal ring SGO3)
Very good chemical properties
Free from halogens and cadmium
Temperature range: -40°C to+105°C
Content of delivery: Flange part, fixation clamps (incl.2 screws),
flange seal (FGO4 or FG04/01), conduit seal ring
(SG03, optional for IP65)
 For technical specification in details, please ask for “Technical Data Sheet” DB-Nr.37000
 |
