VIZG - UNEF metal female thread,strain relief
In railway vehicle and heavy machine construction
For the sparation of damp and dry areas.
Furthermore, these connectors can especially be used where
damp and dry areas have to be separated.
High-grade, specially formulated polyamide 6
Thread made of nickel-plated brass
Very high impact resistance
With integrated strain relief and optimal ingress protection
at the cable (up to IP68 / 5 bar)
Vibration-resistant connection to PMAFLEX conduits
Easy assembly
High thread and system connection strenghts
High conduit pull-out strength
Very good chemical properties
Free from halogens and cadmium
Fits both conduit profiles-fine (T) and coarse (G)
Temperature range: -40°C to+105°C; Short-term: +160°C
Content of delivery:
  For technical specification in details, please ask for “Technical Data Sheet” DB-Nr.35004
 |
