VNDZ - strain relief, straight PG long thread In machine and plant construction.
In railway track side applications.
Where damp and dry areas need to be separated.
Furthermore, these connectors can especially be used where
damp and dry areas have to be separated.
• Specially formulated polyamide 6
• Extremely shock resistant
• Easy installation
• High conduit pull-out strength
• The integrated strain relief element optimally holds and seals cables
• If several conductors are used with the connector multiple sealing
inserts should be considered
• Self-extinguishing
• Free from halogens and cadmium
• Fits both conduit profiles-fine (T) and coarse (G)
• Temperature range: -40°C to+105°C; Short-term: +160°C
• Content of delivery:
IP66: Fitting with pre-assembled universal safety clips (AFN2),
strain relief insert ( up to IP68 / 5 bar )
• For several conductors multiple sealing inserts are available (MDE)
IP66  |For technical specification in details, please ask for “Technical Data Sheet” DB-Nr.25001 標記爲#的産品有最小起訂量（MOQ）, 待定=MOQ需與工廠確認
 |
