VNDZ/VNZ - straight, PG, strain relief In machine and plant construction.
For the separation of damp and dry areas.
Furthermore, these connectors can especially be used where
damp and dry areas have to be separated.
• Specially formulated polyamide 6
• Very high impact resistance, high conduit pull-out strength
• Vibration-resistant connection to PMAFLEX conduits
• Easy mounting
• Integrated strain relief optimally holds and seals cables
• If several conductors are used with the connector multiple sealing
inserts should be considered
• Very good chemical properties
• Free from halogens and cadmium
• Fits both conduit profiles-fine (T) and coarse (G)
• Temperature range: -40°C to+105°C; Short-term: +160°C
• Content of delivery:
IP66: Fitting with pre-assembled universal safety clips (AFN2)
IP68GT: Fitting with pre-assembled universal safety clips (AFN2)
and conduit seal (NVN3-GT); thread gasket (SVN4))
IP68: Fitting with oval clips (OVN2), conduit seal (NVN3) and
thread gasket (SVN4)
• For several conductors multiple sealing inserts are available (MDE)
 * = Replace with “B” to order black or “S” to order grey  |
