VEZ - metric, straight with strain relief, long metal thread Applications for EMC connections in railway
vehicle construction and in machine building in dustry.
Furthermore, these connectors can especially be used
where damp and dry areas have to be separated. High-grade, specially formulated polyamide 6
thread made of nickel-plated brass
Sealing insert made of TPE-V
Very high impact resistance
Vibration-proof connection to PMAFLEX conduits
Pflitsch system UNI HF DICHT with UNI IRIS -Spring
Most commonly available shielded cables can be contacted using
this connector
With the integrated strain relief cables are held optimally
High conduit pull-out strength
Very good chemical properties
Self-extinguishing, free of halogen and cadmium
Fits both conduit profiles-fine (T) and coarse (G)
Temperature range: -40°C to+105°C; Short-term: +160°C
IP66/IP68  For technical specification in details, please ask for “Technical Data Sheet” DB-Nr.46064
標記爲#的産品有最小起訂量（MOQ）, 待定=MOQ需與工廠確認  |
