KEZ - metric, straight with strain relief, metal thread High-grade, specially formulated polyamide 6
thread made of nickel-plated brass
Sealing insert made of TPE-V
Very high impact resistance
Vibration-proof connection to PMAFLEX conduits
Pflitsch system UNI HF DICHT with UNI IRIS -Spring
Most commonly available shielded cables can be contacted using
this connector
With the integrated strain relief cables are held optimally
High conduit pull-out strength
Very good chemical properties
Self - extinguishing, free from halogens and cadmium
Fits both conuduit profiles-fine (T) and coares (G)
Temperature range: -40°C to+105°C; Short-term: +160°C
IP66/IP68/IP69  For technical specification in details, please ask for “Technical Data Sheet” DB-Nr.46363  |
