KEZ - metric, straight with strain relief, long metal thread
Applications for EMC connections in railway vehicle construction and machine building in dustry.
Furthermore, these connectors can especially be used
where damp and dry areas have to be separated. High-grade, specially formulated polyamide 6
thread made of nickel-plated brass
Sealing insert made of TPE-V
Very high impact resistance
Vibration-proof connection to PMAFLEX conduits
Pflitsch system UNI HF DICHT with UNI IRIS -Spring
Most commonly available shielded cables can be
contacted using this connector
With the integrated strain relief cables are held optimally
High conduit pull-out strength
Very good chemical properties
Self - extinguishing, free from halogens and cadmium
Fits both conuduit profiles-fine (T) and coares (G)
Temperature range: -40°C to+105°C; Short-term: +160°C
IP66/IP68/IP69  For technical specification in details, please ask for “Technical Data Sheet” DB-Nr.46364 標記爲#的産品有最小起訂量（MOQ）  |
