KNZ/B - Fire barrier function, IP68+IP69K metric thread straight,
with strain relief and metal thread
Fire barrier function
In railway vehicle construction for carriage connections
and heavy machine construction
For the separation of damp and dry areas.
Furthermore, these connectors can especially be used where
damp and dry areas have to be separated.
High-grade, specially formulated polyamide 6，thread made of
nickel-plated brass，the sealing insert are made from flame retarded TPE
Very high impact resistance
With integrated strain relief and optimal ingress protection at the cable
Tested according to EN45545-3
Easy push-in assembly for maximum installation reliability
Screwdriver required for dismantling，
impeding unauthorised or accidental opening
Space-saving dismantling
Excellent conduit pull-out strength
Fits both conduit profiles-fine (T) and coarse (G)
Temperature range: -50°C to+105°C; Short-term: +160°C
Fire barrier classification:
EN 45545-3: E20 Horizontal
E30 Vertical
 |
||||
