Main technical features

Material: made of halogen free and shock resistant technopolymer on ABS base with resistance to UV rays.

Standard colour: grey RAL 7035.

Resistance to mechanical shocks IK 08 - IK 10 (shocks up to 6-20 J).

Resistance to abnormal heat: up to 650° C (Glow Wire Test,Reference Standard IEC 60695-2-11).

Installation temperature range: minimum -15° C, maximum +60° C.

Smoked scratch-proof doors with safety key.

Door can be blocked while opened to easily access to the switches.

Galvanized steel mounting DIN rail suitable for installation of MCB and RCD protection devices from 48 to 75 mm depth.

90° openable hinged door with holding position device to make maintenance operations easier.

Pre-cuts for conduit or cable inlet of different sizes.

Screw caps for double insulation included.

Power loss in compliance with Standard EN 60670-24.

Reference Standards: EN 60670, EN 50102.

Products meeting the safety objectives of Low Voltage Directive 2014/35/EU (Annex I).

Products in compliance with RoHS II - 2011/65/EU directive + 2015/863/EU.
