Indoor roof mounted coolers
• Injected gasket on cabinet side as standard.
• Inbuilt condensate evaporator with a
particular safety unit blocking the device
in case of a condensate drain failure.
• Standard air filter.
• Textured RAL 7035 standard color. Other
colors are available upon request.
• The connection is performed by means of FROR cables:
- TOP - Overtemperature alarm, door
contact and condensation level alarm.
RS485 serial interface for remote control (on demand).
• Versions with non-standard supply
voltage are available upon request.
• All two-phase and three-phase versions
can be supplied with different voltages,
by changing the internal wiring (follow
diagrams). check the diagrams for available voltages.
Temperature regulating range (factory set) from /to +30°C / +40°C
Noise level 71 dB (A)
Coolant type R134a
Operating cycle type 100%
Weight 72 Kg
 * Standard version with 50 hz frequency. 60hz version on request Optional
SPECIAL COLOR = R9KLM...
AISI INOX 304 FRONT COVER = RIKLM...
AISI INOX 316 FRONT COVER = RI6KLM...
  |
