Ventilation grid
With filter • Material:PC/ABS UV resistant
• Mounting: by means of elastic clips or 4 self-tapping screws
• Filtering media: thermo-linked progressive structure synthetic fibre
• Mounting range: from 1 to 3 thickness from 1 to 2,1 mm
4 and 5 thickness from 1 to 2,5 mm
Storing temperature from -40°C to +70°C
Lifespan L10 a 20°C 50.000 h
Filtering CLASS G3 as per EN 779
Separation grade 85% - DIN 24185
Dust retention capacity 600 g/m2
Protection degree UL TYPE 12
Note
Filter washable approximately 10 times
 |
