ECOR EMC Version Enclosure
CHARACTERISTICS AND COMPOSITION Housing made from sendzimir sheet steel with a thickness of 15/10
painted externally only, without cable entry.
Reversible door made from sendzimir sheet steel with a thickness
of 15/10 to 20/10 based on the dimensions, and painted externally only,
with ø 3 mm double Bit locking system (box and insert in zinc alloy,
stainless steel tab) and conductive and shielding gasket.
Mounting plate made from galvanised steel with a thickness of 20/10
to 25/10 based on the dimensions.
Set of screws for grounding and assembly.
PAINTING
E DUP - cathodic electrophoresis paint with epoxy resin and finish with
thermosetting epoxy-polyester powders for ETA standard electrostatic cycle.
Colour: RAL7035 textured. External paint only.
PROTECTION RATING
NEMA1 compliant with UL508A and UL50.   EMC FOCUS
The Electromagnetic Compatibility Directive applies to active
components that emit/receive electromagnetic waves and that can
create disturbances, thus altering the functionality of the electronic
equipment installed inside the panels.
The provisions of the Directive do not apply to ETA products because
they aren’t a source of electromagnetic waves, but they can act as a
barrier for the waves generated by their internal and external sources.
This provides for a considerable attenuation of the electromagnetic
field’s intensity, and, consequently, the disturbance that it causes
to the equipment.
 |
